SUNSKY brand 3-axle Aluminum Tanker semi-trailer
Item NO.:
Aluminum tankerLead Time:
20-30DAYSProduct Orgin:
CHINABrand:
SUNSKY brandShipping Port:
ANY PORT, CHINAPayment:
T/T; L/CPrice:
$33500/unitMarket Price:
$35000Price Range:
10-50/33000$Color:
OPTION
-
Whatsapp /VIBER :
8613666007515 -
Email:
sunskytrailers@gmail.com
Item: Chinese brand 3-axle Aluminum Tanker semi-trailer
SUNSKY Aluminum Tanker is suitable for carrying Fuel,oil,drink water,milk etc. SUNSKY Trailer can produce Aluminum Tanker with its high technology welding machines. SUNSKY aluminum tanker Trailer has an advantage on technical specifications which is very important for a trailer. We have more than 1000 pcs of Aluminum Tanker capacity per year.
Features:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
1) Manufacturer, 32 years professional experience.
2) Two years guarantee term provided freely.
3) Export more than 1000 units to Africa, Southeastern Asia, and South America.
4) Products can be custom-made according to your design.
Specification:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
|
30,000L-45,000L 3-axle Aluminum Tank Semi-trailer |
|
|
Feature: |
Carry Drink water, Milk, Beer and chemical liquid |
|
Dimension(L*W*H): |
11000*2500*3700mm(30,000L) 11700*2500*3750mm(40,000L) |
|
Model |
SS9350GRYL |
|
Material: |
Aluminum |
|
Compartment: |
3-6 |
|
Capacity(kgs): |
30,000L-45,000L |
|
Tare weight(kgs): |
6,000-7,000kgs |
|
Kingpin |
The world-famous JOST brand bolt-in/welded type 3.5”/2” |
|
Landing gear |
JOST brand two-speed manual operation 19” |
|
Tire size |
11.00R20、11R22.5、12R22.5、315/80R22.5、385/65R22.5 |
|
Rim size |
8.25*22.5、9.00*22.5、11.75*22.5 |
|
Axle |
Original BPW-12T/ FUWA-13T |
|
Leafs spring |
Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring/ Airbag suspension |
|
Brake system |
One unit WABCO RE 4 relay valve; four units T30/30 spring brake chamber; two units T30 spring brake chamber; two units reliable local brand 45L air tank; two units reliable local brand standard coppery air-connector. |
|
Manhole: |
Aluminum alloy ø500mm(20”) manhole with aluminum alloy cover; with breather valve; |
|
Discharge Valve |
Aluminum alloy discharge valve with cover |
|
Foot Valve |
Pneumatic control DN80 aluminum alloy foot valves |
|
Pneumatic Control system |
1set Pneumatic Control combined switch 1unit emergency switch |
|
Discharge Hose |
2 units 3”×6M factory PVC hose with quick coupling on both ends |
|
Vapor Recovery & Overfill system |
Optional |
|
Fire Extinguisher Carrier |
2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside |
|
Electric system: |
One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable |
|
Prime & Topcoat painting |
S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting |
|
We can build the trailers according to customer’s design and requirement |
|
Production detail:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Producing process:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Loading and Packing:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
Our advantage and ability:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
What others we can supply:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
FAQ:
‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑‑
1. Who are we?
Answer: We are a group company; we have three semi-trailer factories in china, one trading company in china and one company inHong Kong. We are focus on semi-trailer, trucks and parts.
2. Why choose us
Answer: 1) We have more than 30years experience in the trailer manufacturing. Our brand”SUNSKY” and”JUPITER” had got high reputation in china and overseas countries.
2) We have more than 20 engineers to design the kinds of trailers according to the requirement from you.
3) We had exported thousands of trailers to Africa, Middle East, Asia,Australia,South America and so on since 2006.
4) We are one of the biggest dealers of SINOTRUK HOWO truck in china, we can supply kinds of HOWO brand truck with competitive price.
